VISUALIZATION, HIGH-ACCURACY, TRACEABILITY

The Best 3D Body Scanner
For Body Assessment

TEKNISKE SPESIFIKAJONER


Hardware

  • Intel depth camera, Class 1 infrared laser for scanning, 100% safety to human

  • Built-in intelligent voice prompt system

  • Gesture recognition: Support interacting with the device for self-service

  • Height restriction: 6ft7in;

  • Weight restriction: 551.16 lbs

Vertikal del

  • Camera: 3 Intel depth cameras for a full body scan, which ensures to generate high-accuracy 3D model

  • RGB camera: Support gesture recognition

  • Handles: Semi-closed design makes it easy to hold steady. There are electrodes on each handles for accurate body composition measurement

Spesifikasjon

  • Dimensions: 685.3mm (length) x 400mm (width) x 1611.5mm (height)

  • Network: Ethernet connection

  • The net weight:43KG

Tablet

  • Interfaces: Micro USB/3.5mm audio/ Micro SD/SIM
    Display 10.1”, 1280 x 800 HD IPS screen
    Network:Wi-Fi / LTE
    OS: Android O
    GSM: B2/B3/B5/B8
    Weight:530g
    Dimensions:247mm x 171mm x 8.9mm

Se rapport

  • After measurement, the coach will assist you to sign in the Visbody APP or website and get your report with a unique code. Also, you can send the report to your mailbox by one click.

  • Supported Printer Model:
    Epson L1119; HP1112
    *Please consult Visbody to confirm whether other models are available.

Connection

  • Require the access to the wired network

SAMMENLIGNET MED ANDRE KROPPSCANNERE
